Magnesium Plate
Technical Specifications & Standard Alloy Grades
Miji Magnesium supplies aerospace and industrial grade magnesium alloy plates manufactured strictly in accordance with ASTM B90 / ASTM B107 standards. Complete Mill Test Certificates (MTC) and SGS/RoHS inspection reports are provided with each production batch.
| Alloy Grade | Standard Tempers | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Primary Application |
|---|---|---|---|---|---|
| AZ31B | O, H24, H26 | 260 – 290 | 180 – 220 | 10 – 15% | General engineering, 3C electronic frames, aerospace brackets, etched printing plates |
| AZ61A | F, T5 | 310 – 340 | 210 – 250 | 8 – 14% | Higher strength structural parts, high-stress automotive components |
| AZ80A | T5, T6 | 340 – 380 | 250 – 290 | 5 – 10% | Heavy-duty forged/milled structural blocks, aerospace fittings |
| ZK60 | T5 | 320 – 360 | 260 – 300 | 8 – 12% | Critical aerospace structures, high-vibration military components |
| WE43 | T6 | 250 – 300 | 170 – 210 | 4 – 8% | High-temperature applications (up to 300°C), specialized defense and motorsport |
Chemical Composition Analysis (wt%)
| Grade | Al (Aluminum) | Zn (Zinc) | Mn (Manganese) | Zr (Zirconium) | Rare Earth (RE) | Mg (Magnesium) |
|---|---|---|---|---|---|---|
| AZ31B | 2.5 – 3.5% | 0.6 – 1.4% | 0.20 – 1.0% | – | – | Balance |
| AZ61A | 5.8 – 7.2% | 0.4 – 1.5% | 0.15 – 0.50% | – | – | Balance |
| AZ80A | 7.8 – 9.2% | 0.2 – 0.8% | 0.12 – 0.50% | – | – | Balance |
| ZK60 | – | 4.8 – 6.2% | – | 0.45% min | – | Balance |
| WE43 | – | – | – | 0.4 – 1.0% | 3.7 – 4.3% (Yttrium) | Balance |
Manufacturing Capacities, Dimensions & CNC Tolerances
- Thickness Range: 0.5 mm to 300 mm (Custom rolling and heavy tooling plates available)
- Standard Width: Up to 1500 mm (Custom slit widths available upon request)
- Standard Length: Up to 6000 mm (Precision saw cut and flat milled)
- Surface Finish Options: Mill Finish, Flat Ground (Pre-milled surface Ra ≤ 0.8 µm), Anodized, Micro-Arc Oxidation (MAO/PEO)
- CNC Machining Tolerance: High-precision milling and turning within ±0.01 mm according to 2D/3D CAD drawings (STEP, IGES, DXF)
Magnesium Alloy Plates for Industrial Applications
Miji Magnesium manufactures and supplies magnesium alloy plates for aerospace, automotive, electronics, tooling and precision engineering applications. Available grades include AZ31B, AZ61A, AZ80A, ZK60 and WE43. Custom cutting and CNC machining services are available according to your drawings and specifications.
Available Magnesium Plate Grades
- AZ31B Magnesium Plate – excellent formability, machinability and general-purpose performance.
- AZ61A Magnesium Plate – higher strength than AZ31B for structural components.
- AZ80A Magnesium Plate – suitable for applications requiring high strength and durability.
- ZK60 Magnesium Plate – high-strength alloy for aerospace and demanding engineering applications.
- WE43 Magnesium Plate – heat-resistant magnesium alloy for aerospace and high-temperature applications.
Magnesium Plate Features
- Low density and excellent strength-to-weight ratio
- Good machinability for precision components
- Effective vibration damping
- Good thermal conductivity
- Suitable for lightweight structural designs
- Available in custom sizes and machined shapes
Custom Sizes and Processing
Magnesium alloy plates can be supplied in different thicknesses, widths and lengths according to project requirements. Miji Magnesium also provides cutting, milling, drilling and custom CNC machining services. Send us your required alloy grade, dimensions, quantity and drawings for confirmation.
Applications
Magnesium plates are widely used for aerospace structures, automotive components, electronic housings, tooling plates, printing and engraving plates, fixtures, machinery parts and lightweight CNC-machined components.
Why Choose Miji Magnesium?
- Multiple magnesium alloy grades available
- Custom plate dimensions and machining
- Support for prototypes and production requirements
- Technical assistance with alloy selection
- International supply and quotation support
Request a Quote
Need magnesium alloy plates for your project? Send your alloy grade, dimensions, quantity and drawings to sales@mijimg.com for a fast quotation.
AZ31B Magnesium alloy sheet, thickness from 0.1mm, can be used for battery cells, electronic frames.
High performance products, military quality, customized from 2mm thickness.
lightweight, high-strength, and corrosion-resistant, ideal for aerospace, automotive, and structural applications.
High-strength, lightweight, corrosion-resistant alloy ideal for aerospace, automotive, and precision components.
Applications & Global Partners
Custom Magnesium Plates: Any Thickness Cut & Shipped Globally
-
Ultimate Lightness: Around 35% lighter than aluminum, providing rapid structural weight reduction.
-
Versatile Thickness Formats: From ultra-thin millimeter sheets to massive heavy-duty thick tooling plates.
-
Zero Sizing Restrictions: Precision cut, flat-milled, and sawed to your exact blueprint measurements.
-
High Thermal Conductivity: Dissipates heat rapidly, making it excellent for sensitive electronic enclosures.
Precision-Milled Production-Ready Plates: Bespoke Ordering Delivered Worldwide
-
Excellent Flattening Precision: Superior surface finish and minimal thickness deviation for immediate CNC milling.
-
Great Vibrational Damping: Absorbs heavy dynamic impact seamlessly to protect fast-moving automotive parts.
-
Fully Traceable Batches: Shipped directly with compliant chemical testing certificates verifying alloy purity.
-
Heavy Sealed Wood Packaging: Vacuum-sealed and crated securely to block any coastal marine moisture.
Why Choose Miji Magnesium for Global Export
Direct-from-manufacturer precision magnesium solutions with certified quality traceability, rapid DFM engineering, and zero-defect export packaging.
Export Anti-Oxidation Packaging
Magnesium oxidizes easily in marine high-salinity air. Every shipment is protected by:
- Vacuum Aluminum Foil Barrier + VCI anti-corrosion film wrapping.
- Heavy-duty Industrial Desiccant bags inside sealed packages.
- ISPM-15 Standard Fumigated Crates with high-density shockproof foam.
Full Quality Traceability & MTC 3.1
100% batch-tested in our accredited metallurgical laboratory before departure:
- EN 10204 3.1 Mill Test Certificate (MTC) provided with chemical & mechanical data.
- Optical Emission Spectrometer (OES) precise elemental analysis.
- Ultrasonic Flaw Detection (UT) and CMM 3D dimensional verification.
Rapid DFM & 24h Quoting
Accelerate your prototyping and mass production with our in-house engineering team:
- Direct CAD / STEP / IGES Evaluation with instant DFM feedback.
- Fast Turnaround: Formal quote within 24 hours.
- Strict NDA Protection for proprietary designs and IP.
